Ragazzini Rotho DF90 Peristaltic Must Pump (65 TPH)

For producers that need to move large volumes of wine and must without sacrificing product integrity, Ragazzini's DF90 is the clear choice.

Request a Quote

Requires Freight Shipping

This item is too large to ship by parcel carriers. We'll ship it on a pallet and reach out to you with freight quotes prior to shipping. Keep in mind that heavier pallets are usually cheaper to ship than lighter ones, so consider adding more items to your order to save on shipping costs overall.

Harvest Order Item

Harvest items arrive from Europe once a year, in time for the wine harvest season.

Usually we get our containers from Europe in late July, sometimes early August depending on port conditions.

If you are interested in purchasing equipment for the current year's harvest, you must place an order with at least 50% deposit no later than April 1st of the same year. You can contact us to place a deposit, or place your order online to secure delivery in time for harvest.

Overview

The DF90 & DF90T are extremely powerful and extremely gentle peristaltic must pumps. It is designed for premium wine producers that are passionate about extremely gentle grape handling, thus ensuring the highest-quality final product.

They are capable of moving pomace and whole grape clusters, as well as fragile and sensitive products like wine and must. They are ideal for pumping over long distances or from considerable depths, and excel at pumping very delicate products.

In contrast to RPD must pumps, Ragazzini Rotho pumps do not need to be guarded from debris that may enter the inlet by mistake. We have seen RPD must pumps ruined by a stray vineyard tie, bits of tape, or even errant Tri Clamp fittings. Ragazzini Rotho peristaltic pumps are capable of simply "pumping through" these mistakes without damage to the pump or the peristaltic tube, saving you valuable manpower hours during the most critical parts of the year.

Specifications:
  • DF90: 6" Inlet & Outlet
  • DF90T includes auger screw must hopper, required for pumping must, crushed destemmed grapes, and whole grape clusters
  • Customer specifies fitting type: Tri Clamp, Camlock, DIN, etc.
  • Dual peristaltic tubes for high throughput
Properties
Crushed & Destemmed Grape Flow Rate65 TPH
Liquid Flow Rate370 GPM
Tri Clamp Inlet/Outlet Size6"
